The gauge stocked against this catalogue line is the Hansen by Danfoss FF14799: a -30 in/Hg
to 30 psi vacuum/pressure gauge on a 1/4" male NPT connection, in a nickel-plated steel case
with a polished brass movement, glycerine fill and an acrylic lens, 2.57" in diameter. It is
built for hydraulics and mineral-based fluids on agricultural, construction and industrial
equipment, and it is a fair default for a general low-pressure or vacuum reading point - but a
gauge is specified wrongly more often than almost anything else on a site, and the errors are
consistent enough to be worth listing before assuming this range fits every position.
The first is range. A gauge is most accurate through the middle of its scale, and choosing one
whose full-scale reading is far above the working pressure means the needle sits near the bottom
of the dial where the reading is least reliable and hardest to read. The convention is to select
a range so that normal working pressure falls around the middle - roughly a half to two thirds of
full scale - which leaves headroom for a surge without wasting the useful part of the dial. A
gauge run permanently near its full-scale limit, conversely, fatigues its element and drifts.
The second is vibration and pulsation. On a hydraulic system, a pump running against a
pulsating load will shake a dry gauge until the needle is unreadable and the movement wears out.
The answer is a liquid filled case: the fill damps the pointer so the reading can actually be
taken, and it lubricates and cushions the movement so the gauge survives. Where a system pulses
hard, a snubber or restrictor in the connection does the rest. This is the single change that
most often turns a gauge that fails every year into one that lasts.
The third is the wetted parts. Whatever the gauge is measuring touches its internals, so the
material of the element and the socket has to be compatible with the medium. Standard brass or
bronze internals are fine for hydraulic oil, water and air; a corrosive process fluid, salt water
or a chemical needs stainless steel or a diaphragm seal that isolates the gauge from the medium
entirely. Case material follows the external environment rather than the medium - stainless for a
salt atmosphere or wash-down area.
Then there are the mechanical questions: the connection thread and size, whether the gauge is
bottom or back connected, whether it is panel mounted with a flange or fitted directly into the
line, and the dial diameter, which is really a question of the distance it has to be read from.
Where the reading has to be logged, alarmed or fed into a control system rather than read by a
person, an electronic pressure transmitter with a 4-20 mA or digital output is the right
instrument instead of a dial.
Where the FF14799's -30 in/Hg to 30 psi range does not suit the duty - a higher-pressure
hydraulic circuit, a corrosive process fluid, a wash-down area - tell us the medium, the
working and maximum pressures, the connection and the environment, and we will specify the
right gauge rather than defaulting to this one.
